2023 Vol.55, Issue 4 Preview Page

Research Article

Sound Absorption Capability of Medicine Herb Residues Mat
Eun-Suk Jang1
,
Nam-Ho Lee2†
,
Chun-Won Kang3‡
1Research Institute of Human Ecology, College of Human Ecology, Jeonbuk National University, Jeonju 54896, South Korea, Sambo Scientific Co. Ltd, R&D Center, Seoul 07258, Republic of Korea, Ph.D. Director
2Department of Wood Science & Technology, College of Agriculture & Life Sciences, Jeonbuk National University, Jeonju 54896, Republic of Korea, Professor
3Research Institute of Human Ecology, College of Human Ecology, Jeonbuk National University, Jeonju 54896, Republic of Korea, Professor
†Corresponding author: E-Mail: enamo@jbnu.ac.kr (Address: Department of Wood Science & Technology, College of Agriculture & Life Sciences, Jeonbuk National University, Jeonju 54896, Republic of Korea)
‡Co-corresponding Author: E-Mail: kcwon@jbnu.ac.kr (Address: Research Institute of Human Ecology, College of Human Ecology, Jeonbuk National University, Jeonju 54896, Republic of Korea)
30 August 2023. pp. 12-20
PDF XML Citation
Abstract

This study investigated the sound-absorbing properties of herbal medicine waste (HMW) as a promising eco-friendly material for sound absorption. The authors examined the sound absorption coefficient by filling impedance tubes with varying heights of HMW (4 cm, 6 cm, 8 cm, and 10 cm). The results revealed that at a filling height of 4 cm, the optimal sound absorption frequency was found to be 1416 Hz, with a sound absorption coefficient of 0.999. Similarly, at a filling height of 12 cm, the optimal sound absorption coefficient was 0.965 at 456 Hz. It was observed that the sound-absorbing performance at lower frequencies improved as the thickness of the sound-absorbing material increased. Based on the standards established in KS F 3503, HMW would receive a sound absorption grade of 0.5M to 0.7M, depending on the filling height. In conclusion, HMW showed excellent potential as a sound-absorbing material, and the results of our testing showed that it can be used as an alternative to synthetic fibers.

Keywords
Herbal medicine wastes
eco-friendly sound-absorbing material
sound absorption coefficient
sound absorption performance
References
1
Yang, T., Association between perceived environmental pollution and health among urban and rural residents-a Chinese national study, BMC Public Health 20(1):1-10 (2020). 10.1186/s12889-020-8204-032028903PMC7006119
2
Jang, E.S. and Kang, C.W., The use of ring-porous East Asian ash (Fraxinus japonica (Thunb.) Steud.) and oak (Quercus spp.) cross-sections as eco-friendly resonance-absorbing materials for building, Wood Material Science & Engineering 17(6):1002-1009 (2022). 10.1080/17480272.2021.1987518
3
Jang, E.S., Sound Absorbing Properties of Selected Green Material-A Review, Forests 14(7):1366 (2023). 10.3390/f14071366
4
Münzel, T., Sørensen, M., and Daiber, A., Transportation noise pollution and cardiovascular disease, Nature Reviews Cardiology 18:619-639 (2021). 10.1038/s41569-021-00532-533790462
5
Ventriglio, A., Bellomo, A., di Gioia, I., Di Sabatino, D., Favale, D., De Berardis, D., and Cianconi, P., Environmental pollution and mental health: a narrative review of literature, CNS spectrums 26(1):51-61 (2021). 10.1017/S109285292000130332284087
6
Putra, A., Or, K. H., Selamat, M. Z., Nor, M. J. M., Hassan, M. H., and Prasetiyo, I., Sound absorption of extracted pineapple-leaf fibres, Applied Acoustics 136:9-15 (2018). 10.1016/j.apacoust.2018.01.029
7
Li, P., Wang, X., Su, M., Zou, X., Duan, L., and Zhang, H., Characteristics of plastic pollution in the environment: A review, Bull Environ Contam Toxicol 107(4):577-584 (2021). 10.1007/s00128-020-02820-132166334
8
Rhodes, C. J., Plastic pollution and potential solutions, Sci Prog 101(3):207-260 (2018). 10.3184/003685018X1529487670621130025551PMC10365157
9
Jang, E. S. and Kang, C. W., Do Face Masks become Worthless after Only One Use in the COVID-19 Pandemic?, Infection & chemotherapy Dec;52(4):583-591 (2020). 10.3947/ic.2020.52.4.58333263241PMC7779990
10
Shellenberger, M. Apocalypse never: why environmental alarmism hurts us all. HarperCollins Publishers, USA. (2020).
11
Hohn, S., Acevedo-Trejos, E., Abrams, J. F., de Moura, J. F., Spranz, R., and Merico, A., The long-term legacy of plastic mass production, Science of The Total Environment 746:141115 (2020). 10.1016/j.scitotenv.2020.14111532745856
12
Han, Y. J. and Lee, S. M., Investigation on the Awareness and Preference for Wood Culture to Promote the Value of Wood: I. Awareness of Wood and Cultural Experience, Journal of the Korean Wood Science and Technology 49(6):616-642 (2021). 10.5658/WOOD.2021.49.6.616
13
Han, Y. J. and Lee, S. M., Investigation on the Awareness and Preference for Wood to Promote the Value of Wood: II. Awareness of Wood Cultural Resources, Journal of the Korean Wood Science and Technology 49(6):643-657 (2021). 10.5658/WOOD.2021.49.6.643
14
Yun, J. H., Shin, H. C., Hwang, W. J., Yoon, S. M., and Kim, Y. S., Identification of Sapstain Fungi on Weathered Wooden Surfaces of Buildings at Jangheung and Jeju Island, Journal of the Korean Wood Science and Technology 49(6):591-601 (2021). 10.5658/WOOD.2021.49.6.591
15
Han, Y. J., Lee, S. M., Choi, J. Y., and Park, C. Y., A study on classification of wood cultural resources in South Korea, Journal of the Korean Wood Science and Technology 49(5):430-452 (2021). 10.5658/WOOD.2021.49.5.430
16
Hwang, J. W. and Oh, S. W., Bending Strength of Board Manufactured from Sawdust, Rice Husk and Charcoal, Journal of the Korean Wood Science and Technology 49(4):315-327 (2021). 10.5658/WOOD.2021.49.4.315
17
Yang, H. S., Kim, D. J., and Kim, H. J., Rice straw-wood particle composite for sound absorbing wooden construction materials, Bioresource Technology 86(2):117-121 (2003). 10.1016/S0960-8524(02)00163-312653275
18
Kang, C. W., Lee, N. H., Jang, S. S., and Kang, H. Y., Sound absorption coefficient and sound transmission loss of rice hull mat, Journal of the Korean Wood Science and Technology 47(3):290-298 (2019). 10.5658/WOOD.2019.47.3.290
19
Sari, N. H., Wardana, I., Irawan, Y. S., and Siswanto, E., Physical and acoustical properties of corn husk fiber panels, Advances in Acoustics and Vibration 2016 (2016). 10.1155/2016/5971814
20
Zulkifli, R., Nor, M. M., Tahir, M. M., Ismail, A., and Nuawi, M., Acoustic properties of multi-layer coir fibres sound absorption panel, Journal of Applied Sciences 8(20):3709-3714 (2008). 10.3923/jas.2008.3709.3714
21
Jang, E. S. and Kang, C. W., Sound absorption characteristics of three species (binuang, balsa and paulownia) of low density hardwood, Holzforschung 75(12):1115-1124 (2021). 10.1515/hf-2021-0049
22
Jang, E. S. and Kang, C. W., The pore structure and sound absorption capabilities of Homalium (Homalium foetidum) and Jelutong (Dyera costulata), Wood Science and Technology 56:323-344 (2022). 10.1007/s00226-021-01336-z
23
Kang, C. W., Li, C., Jang, E. S., Jang, S. S., and Kang, H. Y., Changes in sound absorption capability and air permeability of Malas (Homalium foetidum) specimens after high temperature heat treatment, Journal of the Korean Wood Science and Technology 46(2):149-154 (2018). 10.5658/WOOD.2018.46.2.149
24
Kang, C. W., Choi, I. G., Gwak, K. S., Yeo, H. M., Lee, N. H., and Kang, H. Y., Changes of sound absorption capability of wood by organosolv pretreatment, Journal of the Korean Wood Science and Technology 40(4):237-243 (2012). 10.5658/WOOD.2012.40.4.237
25
Jang, E. S., Investigation of sound absorption ability of Hinoki Cypress (Chamaecyparis obtusa) cubes, Journal of the Korean Wood Science and Technology 50(5):365-374 (2022). 10.5658/WOOD.2022.50.5.365
26
Jang, E. S., Experimental investigation of the sound absorption capability of wood pellets as an eco-friendly material, Journal of the Korean Wood Science and Technology 50(2):126-133 (2022). 10.5658/WOOD.2022.50.2.126
27
Jang, E. S., Investigation of Sound Absorption Ability of Acanthopanax senticosus Wastes, Journal of the Korean Wood Science and Technology 50(6):404-413 (2022). 10.5658/WOOD.2022.50.6.404
28
Kang, C. W., Jang, E. S., Jang, S. S., Kang, H. Y., Kang, S. G., and Oh, S. C., Sound Absorption Rate and Sound Transmission Loss of Wood Bark Particle, Journal of the Korean Wood Science and Technology 47(4):425-441 (2019). 10.5658/WOOD.2019.47.4.425
29
Jung, S. Y., Kong, R. K., Lee, K. S., and Byeon, H. S., Effects of Air-Dried Leaves of Evergreen Broad-Leaved Trees on Sound Absorption Property, Journal of the Korean Wood Science and Technology 49(5):482-490 (2021). 10.5658/WOOD.2021.49.5.482
30
Jang, E. S., Use of Pine (Pinus densiflora) Pollen Cones as an Environmentally Friendly Sound-Absorbing Material, Journal of the Korean Wood Science and Technology 50(3):186-192 (2022). 10.5658/WOOD.2022.50.3.186
31
NIKOM, Korean oriental medicine industry statistics, National Institute for Korean Medicine Development, Korea (2018).
32
Kim, S. B., Moon, G. B., Lee, B. D., Oh, H. R., Bae, H. C., and Lee, S. K., Effects of Molasses Supplementation on the Quality of Galgeuntang Meal Silage and the Palatability in Korean Native Goats, Korean Journal of Agricultural Science 33(1):25-34 (2006).
33
Kim, S. J., Kim, J. Y., and Baek, S. H., Effect of Composted Medicinal Herb Waste on Soil Chemical Properties and Rubus coreanus Miquel (Bokbunja) Quality, Korean Journal of Plant Resources 24(4):472-481 (2011). 10.7732/kjpr.2011.24.4.472
34
Xin, S., Huang, F., Liu, X., Mi, T., and Xu, Q., Torrefaction of herbal medicine wastes: Characterization of the physicochemical properties and combustion behaviors, Bioresource Technolology 287:121408 (2019). 10.1016/j.biortech.2019.12140831085428
35
Wang, H., Lou, X., Hu, Q., and Sun, T., Adsorption of antibiotics from water by using Chinese herbal medicine residues derived biochar: Preparation and properties studies, Journal of Molecular Liquids 325:114967 (2021). 10.1016/j.molliq.2020.114967
36
Jouyandeh, M., Tavakoli, O., Sarkhanpour, R., Sajadi, S. M., Zarrintaj, P., Rabiee, N., Akhavan, O., Lima, E. C., and Saeb, M. R., Green products from herbal medicine wastes by subcritical water treatment, Journal of Hazardous Materials 424:127294 (2022). 10.1016/j.jhazmat.2021.12729434592595
37
Jang, E. S., Peanut Shells as an Environmentally Beneficial Sound-Absorbing Material, Journal of the Korean Wood Science and Technology 50(3):179-185 (2022). 10.5658/WOOD.2022.50.3.179
38
Tudor, E. M., Kristak, L., Barbu, M. C., Gergeľ, T., Němec, M., Kain, G., Réh, R., Acoustic properties of larch bark panels, Forests 12(7):887 (2021). 10.3390/f12070887
39
Jang, E. S. and Kang, C. W., Investigation of sound absorption capability of pine (Pinus densiflora) cone particles, Journal of Wood Science 69(1):1-7 (2023). 10.1186/s10086-022-02075-w
