Development of a Cellulose Nanofibril Production Process from Sea Squirt Tunics

멍게 피낭 유래 셀룰로오스 나노섬유 제조기술 개발

Min Seo Kim1
,
Ji Hyun Tak1
,
Ji Young Lee2†
김 민서1
,
탁 지현1
,
이 지영2†
1Department of Forest Products, Gyeongsang National University
2Department of Environmental Materials Science/IALS, Gyeongsang National University
1경상국립대학교 임산공학과, 대학원생
2경상국립대학교 환경재료과학과/농업생명과학연구원, 교수
†Corresponding Author: E-mail: paperyjy@gnu.ac.kr (Address: Department of Environmental Materials Science/IALS, Gyeongsang National University, Jinju, 52828, Republic of Korea)
30 June 2026. pp. 73-81
PDF XML Citation
Abstract

This study aimed to develop a production process for cellulose nanofibrils (CNFs) derived from sea squirt tunics and to evaluate the feasibility of their surface modification for functional applications. Sea squirt tunics, which contain highly crystalline animal cellulose known as tunicin, were utilized as a sustainable marine biomass resource for CNF production. To enhance nanofibrillation efficiency, enzymatic pretreatment with cellulase was performed at varying enzyme dosages, and the effects on fiber morphology and physicochemical properties were systematically investigated. The results revealed that increasing the cellulase dosage progressively loosened the entangled fiber network of the tunic fibers and reduced the fine content. Among the tested conditions, a cellulase dosage of 5.0% was identified as the most effective for promoting nanofibrillation and was subsequently selected for high-pressure homogenization at 30,000 psi for 50 passes. The resulting enzymatically treated CNF (EN-CNF) exhibited nanoscale fiber dimensions, with an average fiber width of 18.21 nm. To further enhance the functionality and industrial applicability of the produced CNFs, quaternization and carboxymethylation reactions were performed to prepare cationic quaternized CNF (Q-CNF) and anionic carboxymethylated CNF (CM-CNF), respectively. Field-emission scanning electron microscopy (FE-SEM) analysis confirmed successful nanofibrillation in all samples, with average fiber widths of 17.36 nm for Q-CNF and 15.61 nm for CM-CNF. Zeta potential measurements further confirmed the successful introduction of surface functional groups, as Q-CNF exhibited a strong positive surface charge (+41.1 mV). In contrast, CM-CNF displayed a negative surface charge (-22.0 mV). Although the carboxymethylation efficiency of tunicate-derived cellulose was lower than that typically reported for plant-derived cellulose, likely due to its high crystallinity and the presence of residual protein components, the results demonstrated the feasibility of producing surface-modified CNFs from sea squirt tunics. These findings highlight the strong potential of sea squirt tunics as a sustainable marine biomass resource for the production of high-value nanocellulose materials, while simultaneously promoting the recycling and valorization of marine waste.

Keywords
Sea squirt tunic
cellulose nanofibril
tunicin
enzymatic pretreatment
quaternization
carboxymethylation
References
1

Trache, D., Tarchoun, A. F., Derradji, M., Hamidon, T. S., Masruchin, N., Brosse, N., & Hussin, M. (2020). Nanocellulose: From fundamentals to advanced applications. Frontiers in Chemistry, 8, 392.

10.3389/fchem.2020.0039232435633PMC7218176
2

Tofanica, B., Mikhailidi, A., Fortună, M., Rotaru, R., Ungureanu, O., & Ungureanu, E. (2025). Cellulose nanomaterials: Characterization methods, isolation techniques, and strategies. Crystals, 15(4), 352.

10.3390/cryst15040352
3

Klemm, D., Cranston, E. D., Fischer, D., Gama, M., Kedzior, S. A., Kralisch, D., Kramer, F., Kondo, T., Lindström, T., Nietzsche, S., Petzold-Welcke, K., & Rauchfuß, F. (2018). Nanocellulose as a natural source for groundbreaking applications in materials science: Today’s state. Materials Today, 21(7), 720-748.

10.1016/j.mattod.2018.02.001
4

Heise, K., Kontturi, E., Allahverdiyeva, Y., Tammelin, T., Linder, M., Nonappa, & Ikkala, O. (2021). Nanocellulose: Recent fundamental advances and emerging biological and biomimicking applications. Advanced Materials, 33(3), 2004349.

10.1002/adma.20200434933289188PMC11468234
5

Nicu, R., Ciolacu, F., & Ciolacu, D. (2021). Advanced functional materials based on nanocellulose for pharmaceutical/medical applications. Pharmaceutics, 13(8), 1125.

10.3390/pharmaceutics1308112534452086PMC8399340
6

Pennells, J., Godwin, I. D., Amiralian, N., & Martin, D. J. (2020). Trends in the production of cellulose nanofibers from non-wood sources. Cellulose, 27, 575-593.

10.1007/s10570-019-02828-9
7

Das, R., Lindström, T., Khan, M., Rezaei, M., & Hsiao, B. S. (2023). Nanocellulose preparation from diverse plant feedstocks, processes, and chemical treatments: A review emphasizing non-woods. BioResources, 19(1), 1865-1924.

10.15376/biores.19.1.Das
8

Gröndahl, J., Karisalmi, K., & Vapaavuori, J. (2021). Micro- and nanocelluloses from non-wood waste sources; processes and use in industrial applications. Soft Matter, 17, 9842-9858.

10.1039/D1SM00958C
9

Sukhikh, S., Babich, O., Ivanova, S., Kriger, O., Prosekov, A., Noskova, S., Ulrikh, E., Budenkova, E., & Kalashnikova, O. (2024). Production of nanocellulose from miscanthus biomass. Current Research in Green and Sustainable Chemistry, 8, 100412.

10.1016/j.crgsc.2024.100412
10

Achaby, M. E., Kassab, Z., Aboulkas, A., Gaillard, C., & Barakat, A. (2018). Reuse of red algae waste for the production of cellulose nanocrystals and its application in polymer nanocomposites. International Journal of Biological Macromolecules, 106, 681-691.

10.1016/j.ijbiomac.2017.08.067
11

Gao, P., Yen, K. H., Wibowo, A., Zhen, Y., Peng, C., & Miao, W. (2024). Chemical compositions and nutritional profiles of two edible tunicate species (Halocynthia roretzi and Halocynthia aurantium). Heliyon, 10(12), e32321.

10.1016/j.heliyon.2024.e3232138948036PMC11209008
12

Flammang, P., Song, G., Delroisse, J., Schoenaers, D., Kim, H., Nguyen, T. C., Leclère, P., Hwang, D., & Harrington, M. J. (2020). Structure and composition of the tunic in the sea pineapple Halocynthia roretzi: A complex cellulosic composite biomaterial. Acta Biomaterialia, 111, 290-301.

10.1016/j.actbio.2020.04.038
13

Kononova, S., Khripunov, A., Romanov, V. N., Orekhov, A., Mikhutkin, A., Vlasova, E., Lukasov, M. S., & Klechkovskaya, V. (2022). Animal cellulose with hierarchical structure isolated from Halocynthia aurantium tunic as the basis for high-performance pressure-resistant nanofiltration membrane. Membranes, 12(10), 975.

10.3390/membranes1210097536295735PMC9607593
14

Kimura, S., Nakayama, K., Wada, M., Kim, U.-J., Azumi, K., Ojima, T., Nozawa, A., Kitamura, S., & Hirose, E. (2015). Cellulose is not degraded in the tunic of the edible ascidian Halocynthia roretzi contracting soft tunic syndrome. Diseases of Aquatic Organisms, 116, 143-148.

10.3354/dao02913
15

Zhao, Y., & Li, J. (2014). Excellent chemical and material cellulose from tunicates: Diversity in cellulose production yield and chemical and morphological structures from different tunicate species. Cellulose, 21, 3427-3441.

10.1007/s10570-014-0348-6
16

Iwamoto, S., Kai, W., Isogai, A., & Iwata, T. (2009). Elastic modulus of single cellulose microfibrils from tunicate measured by atomic force microscopy. Biomacromolecules, 10(9), 2571-2576.

10.1021/bm900520n
17

Choi, B. D., Kim, J., Park, S. Y., & Lee, J.-S. (2025). Simultaneous extraction and characteristics of high-concentrations dietary fiber and chondroitin sulfate from ascidian tunics: Microstructure and physicochemical analysis. Journal of Chitin and Chitosan, 30(1), 28-35.

10.17642/jcc.30.1.4
18

Lee, J. Y., Kim, K. M., Kim, S. H., Jo, H. M., & Kim, C. H. (2019). Study on the quaternization reaction conditions for cationic cellulose nanofibril. Journal of Korea TAPPI, 51(6), 144-151.

10.7584/JKTAPPI.2019.12.51.6.144
19

Jo, H. M., Lee, S. H., Lee, J. Y., & Park, N. S. (2022). Development of domestic taylor-flow nanogrinder for manufacturing cellulose nanofiber II - Evaluation of physical properties of carboxymethylated cellulose nanofibers made from bleached kraft pulps -. Journal of Korea TAPPI, 54(6), 34-42.

10.7584/JKTAPPI.2022.12.54.6.34
20

Pedrosa, J. F. S., Rasteiro, M., Neto, C. P., & Ferreira, P. (2022). Effect of cationization pretreatment on the properties of cationic Eucalyptus micro/nanofibrillated cellulose. International Journal of Biological Macromolecules, 201, 468-479.

10.1016/j.ijbiomac.2022.01.068
21

Kim, H.-J., Roy, S., & Rhim, J.-W. (2021). Effects of various types of cellulose nanofibers on the physical properties of the CNF-based films. Journal of Environmental Chemical Engineering, 9, 106043.

10.1016/j.jece.2021.106043
22

Lee, S. H., Jo, H. M., Kim, D. H., Lee, J. Y., Han, J. H., & Yun, K. Y. (2022). Evaluation of the physical properties of carboxymethylated cellulose nanofiber derived from red algae pulp. Journal of Korea TAPPI, 54(4), 25-33.

10.7584/JKTAPPI.2022.08.54.4.25
23

Han, N., Weon, S. H., Han, J., Cha, J., & Lee, S. H. (2025). Two-step carboxymethylation of cellulose from Halocynthia roretzi using ionic liquid. Biomacromolecules, 26(5), 2909-2921.

10.1021/acs.biomac.4c01770
